The box cover is made of alloy materials;
Integrated wall-mounted design, integrated network audio decoding, digital power amplifier and speakers;
Using high-speed industrial-grade dual-core (ARM + DSP) chip, start-up time ≤ 1 second;
Built-in high-fidelity linear array speakers and stereo Class D power amplifier;
Built-in loop detection function, can remotely monitor the working status of the speaker, easy maintenance;
The terminal supports remote control of service software to adjust the volume;
Standard RJ45 network interface, can be accessed where there is an Ethernet port, supports cross-network segment and cross-route;
Automatically power off without signal, turn on automatically with signal, support service software to adjust volume;
型号
|
SE-8040
|
SE-8060
|
SE-8090
|
额定功率(W)
|
40W
|
60W
|
90W
|
网络通讯协议
|
TCP、UDP、ARP、ICMP、IGMP
|
||
音频编码
|
MP2/MP3/PCM/ADPCM
|
||
音频采样、位率
|
8KHz-44.1KHz, 16位, 8Kbps-320Kbps
|
||
信噪比
|
≥90dB
|
||
频率响应
|
20Hz-20KHz
|
||
灵敏度
|
92dB
|
||
网络声音延迟
|
广播延迟≤100ms
|
||
防护等级
|
IP×6防水
|
||
尺寸(W×H×D)
|
150×125×415mm
|
150×125×515mm
|
150×125×615mm
|
重量
|
3.2Kg
|
4.3Kg
|
5.1Kg
|
