Uses: access to the alarm signal of the fire center to trigger the playback of alarm voice.

product description:

32-channel alarm input interface (supports 2 ways to trigger: switching ＆#118alue and 24V input), connect the signal from the fire center;

8-channel alarm output interface (normally open contact, DC24V / 1A), which can be connected with external alarm lights to display the alarm status;

Any number of IP network alarm matrices can be used in the system to expand and increase the number of input ports;

Automatically send alarm information to the server, the server executes the corresponding alarm playback task (supports adjacent layer / area alarm);

The alarm sound file is pre-stored in the server, eliminating the "alarm generator";

Standard RJ45 interface, can be accessed where there is an Ethernet port, supports cross-network segment and routing;

Product parameters:

Network communication protocols: TCP, UDP, ARP, ICMP, IGMP

Network chip rate: 10 / 100Mbps

Interface: 1 RJ45 network port, 32 alarm input, 8 alarm output;

Working temperature and humidity: -10 ℃ ~ 70 ℃, ≤90% RH;

Power supply, power consumption: AC 220V ≤15W

Dimensions (W × H × D): 483 × 259 × 44mm

Weight: 2.7Kg
