Features:

-Standard chassis design, 2U aluminum alloy brushed panel; user-friendly drawing design, beautiful and practical

-10 line inputs, monitor 10 partitions; you can arbitrarily select the sound of the monitored partition;

-Built-in high-fidelity 5W / 8Ω full-frequency monitor speaker, full and clear sound quality;

-The monitoring volume can be adjusted;

-Band switch to select monitoring channel;

-It can monitor normally even without power on.

Technical Parameters

-Line input: 70V / 100V, audio signal;

-Number of lines that can be monitored: ten channels ‘CH1 ~ CH10’;

-Monitor speaker: Built-in high-fidelity ‘HiFi’ full-range speaker, 5W;

-Power cord: (3 × 0.75 mm2) × 1.5M (standard);

-Power supply: AC 220V ± 10% 50-60Hz;

-Power consumption: 10 ~ 15W;

-Machine size: 88 (H) × 485 (W) × 340 (D) mm;

-Net weight: 6.5kg;
