Features:

-High-grade aluminum 2U silver brushed panel, beautiful and elegant;

-First choice for power management of public address system;

-Turn on / off the power supply of 16 controlled devices in order to protect the power grid from impact;

-The 16-way power socket is turned on or off in sequence. The difference between the on and off times of each channel is 1S.

-The total output capacity of the machine is up to 6KW;

-The rear output block can be completely powered off after shutdown;

-The power input cable of this machine is directly connected to the automatic air switch of industrial appliances;

-16 channels of power can be turned on / off regularly with the system timer;

-Concise LED working status indicator.

Technical Parameters

-Single channel capacity: 3KVA

-Total capacity: 6KVA

-Control signal: AC 220V, 10Ma;

-Action time interval: 0.4S ~ 0.5S;

-Channel switching capability: 2 kW (VA);

-Controllable power output: 16 channels (CH1 ~ CH16);

-Power cord: (3 × 1.5 mm2) × 1.5M (standard);

-Power supply: AC 220V ± 10% 50-60Hz;

-Power consumption: 25 ~ 30W;

-Machine size: 88 (H) × 485 (W) × 340 (D) mm;

-Net weight: 7.5kg;
