Features:

-4.3 inch TFT true color screen display, graphical interface, full touch screen operation, capacitive screen, Android mobile phone operation experience;

-Equipped with PC-side programming software, which can be connected to PC via USB cable;

-Can connect to two 4.3-inch remote touch screen call consoles, the remote control station interface can be displayed and synchronized with the host remotely, and synchronous operation (support NC models);

-RS485 bus, serial COM two communication protocols, easy to connect with other peripheral systems (support CNC models);

-Built-in 8G / TF card or external U disk, can be increased to 16G, 32G, the memory size is your choice;

-Chinese song name display, click to play on touch screen, one click to play, power management;

-With monitoring function, can monitor whether the local equipment and remote equipment are online;

-Can play the memory TF card or U disk music regularly, can insert U disk to play music, there is no requirement for the name of the song in the U disk, the song placement path, you can click the up and down song to play;

-Support computer online editing of timing programs, manual programming, automatic operation offline;

-Contains 4 sets of programs, each program can be programmed with 120 timing points;

-Built-in high-definition FM radio, which can manually and regularly broadcast radio stations, full-band automatic search, manual search, automatic save, manual quick save, multiple modes;

-Fire fighting function, short circuit or DC12 ~ 24V signal input, automatic alarm, fire short circuit output;

-1 local microphone input, 2 line input, 4 audio output, 2 remote microphone signal output;

-The microphone voice mute level can be set, and the microphone partition power trigger can be set;

-Built-in high-fidelity 3W / 8Ω, hi-fi full-range speaker, monitoring function, monitoring can be turned on and off;

-With monitor function, the monitor volume can be adjusted;

-High precision RTC clock, timing can be accurate to second;

-With Fats file system, you can use Notepad to program without using any software;

-With remote upgrade function, you can use TF to upgrade the firmware;

-Powerful music playback function, support MP3 and other audio formats, can support up to 999 songs, 32G memory, you can view the first 200 songs in the memory song name, displayed by page, one page can display 6 songs, convenient and intuitive;

-With 8-way partition, 6-way power supply, timing and manual control, 6-way independent control timing power output port;

-The machine has built-in use help, it will not be operated. Click on the use help to give detailed guidance, and the built-in broadcast engineering construction guide;

-You can set the partition and power on time in advance;

-With RS485 bus, you can control CNC equipment such as CD player, tuner, partitioner, radio, etc. (support NC models);

-With user name login interface, user name and password login, password modification, password management functions;

-Quick music playback experience, with the same playback icons and interface as mainstream playback software such as Kugou;

-Can inquire and monitor the online status of other access devices (support CNC models);

-2U chassis, aluminum alloy panel, standard body.
